SJ90 Rubber sheathed cable continuous vulcanization catenary line to Brazil

SJ90 Rubber sheathed cable continuous vulcanization catenary line to Brazil       SJ90/16 Rubber sheathed cable continuous vulcanization catenary line Technical parameters Use SJ-90 extruded rubber sleeve continuous vulcanization unit is a special machine for cold feeding rubber sleeve extrusion molding, suitable for the production of insulation sheaths for rubber cables such as natural, styrene butadiene, green butadiene, nitrile, ethylene propylene, chlorinated polyethylene, chlorosulfonated polyethylene, silicone rubber, etc. 2. The main technical parameters 2.1 Diameter before extruding Φ5.0-Φ16mm 2.2 Diameter after extruding Φ7.0-Φ30mm 2.3 Heating form Steam 2.4 Cooling form Water 2.5 Vulcanization Tube length 42m 2.6 Tube specification DN159*6 length of 24M, cooling tube 100*6 Length 18M 2.7 Tube material Stainless steel seamless steel tube 2.8 Tube catenary angle Inclined type 7.5° 2.9 Pay-off reel size PN1000-PN2000 2.10 Take-up reel size PN1000-PN2000 2.11 Upper belt wheel type capstan Diameter of traction wheel Φ1200mm: traction force 1500kg 2.12 Front caterpillar max traction force 1500kg 2.14 Production line speed 50m/min 2.15 Power supply Ground and neutral 3-phase 380V 60Hz 2.16 Compressed air 8MPa 2.17 Cable max tension 500kg 2.18 Cable movement direction Right to Left     Tel: +86-18606615951 Max Xu - China wire machinery expert

Planetary strander 630/6 delivery to USD Dacon

1. Equipment usage and advantage It is widely used for stranding Cooper, Aluminum, steel, control, telecom wire, small size plastic power wires and insulated core wires. It is also with tapping function. It uses PLC process control, touch screen, frequency controller and air control systems. The synchronization function deviation value is less than 3% when it launches, running, machine halt, scramming situations. This makes stranding pitch steady. The whole equipment operated by human-computer interface, colorful touch screen with advanced electrical system. 2. Specifications 3. Single wire diameter Cooper：φ1.5-5.0mm Aluminum：φ1.8-5.0mm Steel：φ0.9-3.6mm Al-clad steel：φ1.5-4.5mm Insulated wire：φ3.0-13mm 3.1. Max stranding diameter φ40mm 3.2. Stranding speed range 80r/min. 3.3. Motor power 45KW（AC） 3.4. Pay-off in cage PND630 3.5. Pay-off tension in cage Mechanical friction tension 3.6. Stranding Pitch 63-700mm（stepless regulation） 3.7. Max Linear speed 35m/min. 3.8. taped head max speed 600r/min 3.9. Taped head pitch 16-200mm（stepless regulation） 3.10. Taping machine power 2.2KW(AC) 3.11. Pay-off Bobbins range PND500/PND630 3.12. Capstan diameter φ1200mm 3.13. Capstan Motor power 22KW（AC） 3.14. Take up bobbin PN800-PN1600 3.15. Take up motor power 4.0KW（AC）   4. Components 4.1. Φ630 fixed pay-off loader 1set 4.2. 6 bobbins strander 1set 4.3. Wire Combined module 1set 4.4. Concentric type taping machine 1set 4.5. Self-adapting length counter 1set 4.6. φ1200 dual-wheel capstan device 1set 4.7. Φ1600 gantry type take-up loader 1set 4.8. Electrical control system 1set 4.9. Safety device 1set

BEYDE will be attend Dusseldorf Wire China Exhibition

Hebei Hexing Electrical Machinery Co., Ltd. is located in Hejian City, Hebei Province. It is an important manufacturer of specialized electrical machinery equipment and wire rope twisting equipment in the domestic industry. Since 1983, thanks to the rapid development of the social economy and the care and support of a large number of customers, Hexing Company has focused on research and development in the electrical and mechanical industry, and has obtained multiple national patent certifications. Continuously advancing and growing, it has played an important role in the research and development and manufacturing of wire and cable specialized equipment manufacturing industries both domestically and internationally, and has emerged in the steel wire rope twisting specialized equipment industry. Adhering to the business policy of "professional manufacturing, innovative research and development, and sincere service", we strive to become a first-class manufacturer of wire and cable specialized equipment at home and abroad, and a leading manufacturer of wire rope twisting specialized equipment. In the past forty years, with years of rich experience in serving the cable industry, Hexing Company has continuously innovated and upgraded its product lines, providing high-quality products, strong technical support, and comprehensive after-sales service to customers in more than 30 countries and regions including the United States, Russia, Brazil, India, Kazakhstan, South Korea, Vietnam, Thailand, and other countries and regions. It is a trustworthy partner for domestic and foreign customers

Beyde will attend cablex exhibition in Russia

BEYDE will participate in the Russian CABLEX cable exhibition from March 17 to 21, 2024. Max Xu will demonstrate the company's equipment during the exhibition. As China's leading cable equipment manufacturer, he will bring good prices and high-quality products.

Planetary type laying machine 1250 to Thailand

Our latest cable forming machine 1250/1+1+3 has been sent to the Thai cable company, equipped with filling, metal and non-metal wrapping functions. this company bought from Max Xu +8618606615951 whatsapp

Celebrating the Brazilian company's purchase of 12+18/630 Rigid stranding machine

Warmly celebrate the purchase of the latest independent motor frame winch 630/12+18 by Brazil COPPERFIO. The machine has been completed in June 2021. After 40 days of transportation and 20 days of installation, the machine has been running normally.

Tanzania purchaseed 5 sets of bow type laying-up machine

    Tanzania purchaseed 5 sets of bow type laying-up machine   In 2018, Tanzanian customers came to the Shanghai Exhibition. We had our first contact. After three months of negotiation, the customer purchased a bow stranding machine. In 2022, the first machine was used very well. The customer was responsible for the overhead cable project of the Tanzanian government, and another 5 bow type laying up machine were added. Due to the epidemic, customers can't come to the factory. At the same time, customers trust us very much. During the first factory inspection, customers very much recognize our own processing capacity.

Drum Twister to Lebanon cable factory

  1. Overview 1.1 Equipment purpose CPD2500 winch crawler traction type cabling machine is mainly used for the stranding and cabling of large section and long power cables. The pre twisted or non pre twisted cable cores can be twisted into cables respectively. Steel wire armouring is also available. 1.2 Equipment composition and description This machine is mainly composed of Ф 1600 rotary paying off stand (4 sets) Ф 2500 rotary paying off rack (1 set), filling rope paying off rack, conductor support, three row wire mold base, 42 coil wire paying off rack (2 sets), 84 wire pretorque devices, rotary wire mold base Φ 600 double winding device (1 set) Φ 800 steel belt armor device (1 set), 5T rotating crawler traction device Ф 2500 rotary winding frame, electric drive and control system, pneumatic hydraulic system, etc. The machine adopts the programmable controller to command and coordinate the starting, running and synchronous rotation of the whole machine and the motors of each branch. The AC motor of each branch is controlled by the imported frequency converter. The touch screen is used to display and adjust the operation status and process parameters of the production line. The electric control system is advanced in technology, convenient in operation and reliable in operation. The rotary crawler traction device and the rotary take-up stand of the machine are mechanically linked and rotate synchronously. The traction wire speed is controlled by a separate motor, and the pitch is stepless. The wrapping device is driven by a separate motor, and the wrapping pitch is stepless adjustable. The paying off rack is driven and rotated by a separate motor, which can rotate synchronously with the rotating take-up rack or jog independently. The take-up frame adopts the supporting wheel structure, which increases the rigidity, stability and reliability of operation. The machine is equipped with multiple safety protection and fault automatic shutdown devices, which are easy to operate, safe and reliable. 2. Basic technical specifications of equipment 2.1 Maximum outer diameter of cabling Ф 100mm 2.2 The maximum speed of the winch and pay off stand is 40r/min 2.3 Maximum traction linear speed 50m/min (stepless adjustable) 2.4 Cabling pitch 200 ～ 8000mm 2.5 Maximum traction force 5 tons 2.6 Maximum speed of non-metallic wrapping 650rpm 2.7 Specification of filling rope (outer diameter X hole diameter X width X quantity) Ф 400X Ф 22X360X10 Ф 800X Ф 52X320X4 2.8 Specification X quantity ¢ 500X ¢ 125X375X84 of steel wire armored wire reel 2.9 Main motor N=45KW (AC) n=1500rpm 2.10 Central rotary paying off frame motor (1 set): N=22KW (AC) n=1500rpm 2.11 Side pay off frame rotating motor (4 sets): N=15KW (AC) n=1500rpm 2.12 Traction motor: N=22KW (AC) n=1500rpm 2.13 Non metal wound motor: N=11KW (AC) n=1000rpm 2.14 Steel belt armouring machine: N=22KW (AC) n=1500rpm 2.15 Flat wire motor: N=2.2KW n=1500rpm 2.16 Wire take-up motor: N=5.5KW (AC) n=1480rpm 2.17 Specification of central pay off reel: PN2500 2.18 Specification of side pay off reel: PN1600 2.19 Specification of take-up reel: PN2500 3. Structure description and technical parameters of main components three point one Ф 1600 rotary paying off stand 3.1.1 Structure description The structure of this part is fork cantilever type. The utility model is composed of a driving motor, a reducer, a pneumatic brake device, a fork frame, a coil clamping mechanism, a horizontal pin, a tension control mechanism, etc. The pay off stand uses AC variable frequency motor to drive the fork stand to rotate independently, and the AC variable frequency motor drives the fork stand to rotate after decelerating through helical gear reducer, gear, etc. The paying off rack can rotate synchronously with the take-up rack; It can be fixed without rotation; The inching rotation can also be controlled manually. The paying off tension of 1600 rotary pay off rack is pneumatically controlled. Compressed air is sent to the rotary fork rack by a rotary pneumatic connector, and then acted on the tension disc by two tension controllers. The paying off tension can be adjusted at will on the pneumatic control cabinet under shutdown and running conditions. Note: The rotary pneumatic joint at the end of the spindle should be lubricated frequently during use, otherwise the sealing elements in the joint will be damaged. The clamping of the pay off reel is electrically controlled. The motor drives the center forward and backward through the belt transmission pair, worm gear and worm pair, nut screw pair, etc., so as to clamp or loosen the wire reel. The paying off rack is equipped with a horizontal pin, which is composed of a pin, two travel switches, etc. It is one When the fork is in the horizontal position, the pin installed on the base can be inserted into the round hole at the end of the fork. One travel switch acts. At this time, the reel clamping mechanism and the hydraulic lifting table can work. It is used to complete the clamping, loosening and up and down work of the reel. At the same time, the host cannot be started due to interlocking. When the latch returns, the other travel switch acts. At this time, the host can be started to run and the reel clamping mechanism is locked.
